Hordhac
Saliidda Tubka Haydarooliga ee SAE waa kuwo sare- qaybaha isku xidhka waxqabadka looguna talagalay badbaado, daadsan{1}} wareejinta dareeraha cadaymaha ee nidaamka biyo-xidheenka dalbanaya. Waxaa loo soo saaray heerarka SAE J518 iyo ISO 6162, flanges-yadani waxay xaqiijinayaan waxqabadka la isku halayn karo ee{5}} codsiyada cadaadiska ee warshadaha kala duwan.
Tilmaamaha
|
QAYBTA NO. |
QAYBKA CALANKA |
HOSE BORE |
CABIRKA |
|||||
|
DN |
DASH |
A |
C |
D |
H |
L |
||
|
87641-08-08 |
1/2" |
12 |
08 |
58.9 |
31.7 |
24 |
24 |
7.75 |
|
87641-08-12 |
1/2" |
20 |
12 |
74.9 |
31.7 |
24 |
27.5 |
7.75 |
|
87641-12-10 |
3/4" |
16 |
10 |
72.5 |
41.3 |
32 |
28.2 |
8.76 |
|
87641-12-12 |
3/4" |
20 |
12 |
79.2 |
41.3 |
32 |
31.8 |
8.76 |
|
87641-16-16 |
1" |
25 |
16 |
90.2 |
47.6 |
38 |
34.7 |
9.53 |
|
87641-20-20 |
1.1/4" |
32 |
20 |
103.8 |
54 |
44 |
41.5 |
10.29 |
|
87641-24-20 |
1.1/2" |
32 |
20 |
105.8 |
63.5 |
51 |
45.1 |
12.57 |
|
87641-24-24 |
1.1/2" |
40 |
24 |
116.2 |
63.5 |
51 |
45.5 |
12.57 |
|
87641-32-24 |
2" |
40 |
24 |
125.4 |
79.4 |
67 |
54.7 |
12.57 |
|
87641-32-32 |
2" |
50 |
32 |
135.7 |
79.4 |
67 |
52.7 |
12.57 |
Halbeegyada/Xogta Farsamada
|
Asalka |
ZheJiang, Shiinaha |
Taariikhda keenista |
La gorgortami karo |
|
Shahaado |
GB/T19001-2016 idt ISO9001:2015 |
Baakad |
heerka dhoofinta |
|
Qalab |
Birta Kaarboonka |
Dammaanad |
1 sano |
|
Mudada lacag bixinta |
TT |
MOQ |
2000 |
|
Xaalad |
Cusub |
Midabka |
Zinc cad, zinc midabka |
Ku saabsan Shirkadda
Faa'iidooyinka
Waxqabadka Cadaadiska Aan La Barkin
Lagu farsameeyay in uu u adkaysto ilaa 10,000 PSI cadaadiska dilaaca
30% qiimaynta cadaadiska ka sareeya shuruudaha SAE caadiga ah
Waxay ilaalisaa hufnaanta shaabadda iyadoo ay ku hoos jiraan xaaladaha baaskiilka cadaadiska ba'an
Heerarka Waxsoosaarka Saxda ah
CNC waxaa loo mariyay ± 0.005" dulqaad ku habboon ku habboonaanta
Dhisme been abuur ah (aan la tuurin) si loo helo xoog sare
Micro{0}} dusha daboolida dhammaatay (Ra <0.4μm)
Tayada Agabka Sare
Diyaarada{0}}birta kaarboonka darajada oo leh caabbinta daalka oo la xoojiyey
316L ikhtiyaar bir ah oo leh 5x iska caabin daxaleed
Raadinta walxaha buuxa oo wata shahaadooyinka tijaabada shiidka
Daadin -Dammaanad caddaynaysa
Quad-ka-lahaanshiyaha{0}Teknooloojiyada Seal™ (asaasiga ah, sare, iyo shaabadood ee laba-jibbaaran)
Horay loo rakibay{{1}sare{1}FKM O{2}}fargado (-65 darajo F ilaa +400 darajo F)
100% cadaadis lagu tijaabiyay 1.5x cadaadis shaqo
Warshadaha{0}} Waaritaanka hogaaminta
50% nolosha adeegga ka dheer heerka warshadaha
Meelo gaar ah oo engegan oo loogu talagalay codsiyada dareeraha xoqan
Saamaynta{0}Nashqada u adkaysata ee deegaanka gariirada sare-
U Hogaansanaanta Caalamiga ah & Shahaadada
Shahaado siisay SAE J518, ISO 6162, iyo ASME B16.5
PED 2014/68/EU waafaqsan
ABS iyo DNV{0}}GL oggolaanshaha badda waa la heli karaa
Faa'iidooyinka Rakibaadda
Laser{0}}calamadaha aqoonsiga dhejisan ee hanuuninta fudud
Horay -waxaa la isugu keenay hagayaasha toosinta
40% ka dhakhso badan rakibidda marka loo eego garbaha caadiga ah
Awoodaha wax ka beddelidda
Waxaa lagu heli karaa cabbirro min 1/4" ilaa 6"
Qalab gaar ah oo ay ku jiraan Monel, Hastelloy, iyo titanium
Habaynta dekeda gaarka ah iyo qiimaynta cadaadiska
Hubinta Tayada Adag
Xaqiijinta cabbirka 100% ee CMM
Tijaabada Ultrasonic ee hufnaanta alaabta
Raadinta Dufcadaha oo wata lambaro taxane ah oo gaar ah
Taageerada Farsamo ee Aan La Helin
Kooxda injineernimada codsiga u go'ay
Falanqaynta nidaamka hydraulic ee bilaashka ah
On -Tababarka rakibaadda goobta ayaa diyaar ah
FAQ
S: Waa maxay heerarka ay garabyada SAE u hoggaansamaan?
J: Garabkeena waa kulmaan:
SAE J518 (Koodhka 61 & 62)
ISO 6162 (Taxanaha 1 & 2)
DIN 20066
ASME B16.5 (marka la codsado)
S: Waa maxay qiimaynta cadaadiska ee la heli karo?
A: Heerka cadaadiska caadiga ah:
3000 PSI (207 bar) taxanaha caadiga ah
6000 PSI (414 bar) cadaadis sare{2}
Nashqada khaaska ah ilaa 15,000 PSI (1034 bar)
S: Maxaa agab ah oo aad bixisaa?
A: Agabka caadiga ah:
AISI 4130 steel carbon
304/316 ahama
Alaabooyin gaar ah:
Duplex 2205
Inconel 625
Titanium Fasalka 5
S: Sideen ku doortaa cabbirka garabka saxda ah?
A: Halbeegyada xulashada muhiimka ah:
Cabbirka magaca tuubada (NPS)
Cadaadiska shaqada nidaamka
Shuruudaha socodka (GPM)
Kala duwanaanta heerkulka
Injineeradayadu waxay bixiyaan la talinta cabbirka bilaashka ah
S: Waa maxay fursadaha xidhitaanka ee jira?
A: Habaynta xidhida
O - giraanta wejiga shaabadda (ORFS) - heerka
RTJ (Nooca Giraanta)
Waji fidsan oo leh gaas boog wareeg ah
Birta - ilaa - biraha shaabada ee loogu talagalay abka heerkulka sare{2}
S: Garaafkaagu ma la beddelan karaa noocyada kale?
J: Haa, garabkeena:
Ilaali u hoggaansanaanta cabbirka SAE/ISO oo dhammaystiran
100% waa la beddeli karaa naqshadaha caadiga ah
Ku dar dulqaadka{0}} sagxadaha is-daawashada ee la xakameeyey
S: Waa maxay wakhtigaaga hogaanka ee dalabaadka gaarka ah?
A: Waqtiyada wax soo saarka:
Alaabta kaydka ah: shixnad 24-saac ah
Caadada caadiga ah: 5-7 maalmood oo shaqo
Alloys gaar ah: 2-3 toddobaad
boosaska wax soo saarka degdega ah ayaa diyaar ah
S: Ma bixisaa taageero rakibaadda?
J: Xidhmada taageerada dhamaystiran:
Xisaabiyeyaasha torque-ga dhijitaalka ah
animations rakibaadda 3D
Hagaha rakibaadda garoonka
On - dirida farsamayaqaanka goobta (ikhtiyaar)
S: Waa maxay shahaadooyinka aad haysatid?
A: Shahaadooyinka hadda:
ISO 9001: 2015 (QMS)
API Q1 ( Saliid & Gaas )
PED 2014/68/EU Qaybta IV
DNV{0}}GL Marine
S: Maxaa dayactir lagu talinayaa?
A: Dayactirka ka hortagga:
Xaqiijinta qulqulka sannadlaha ah
Kormeerka shaabadda labadii sanaba mar
5-sano baaritaanka ultrasonic
Beddelka ka dib 50,000 wareeg
